airFiber 11 High-Band Backhaul Radio with Dish Antenna
$1,499.00
Sold Out
airFiber 11 Low-Band Backhaul Radio with Dish Antenna
$1,499.00
Sold Out
airFiber 11
AF-11
$999.00
Sold Out
Compact, point-to-point radio system that operates at 11 GHz frequency.

11 GHz, 300+ km link range

1.2+ Gbps throughput

Distinct RX and TX frequencies

1+ Mpps processing

To subscribe to back in stock e‑mails.
Technical Specifications
Mechanical
Dimensions327 x 112 x 86 mm (12.9 x 4.4 x 3.4")
Weight2.3 kg (5 lb)
MountingAF-11G35 mount compatible
Hardware
Networking interface(1) GbE RJ45 port
(1) 10/100 MbE RJ45 port
Power methodPassive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
Terminal block direct-wire
Power supply50V DC, 1.2A gigabit PoE adapter (Included)
Supported voltage range38-56V DC
Max. power consumption36W
RF connectors(4) SMA Weatherproof, Two per Chain: TX 0, RX 0 (Chain 0) and TX 1, RX 1 (Chain 1)
(2) N-Type Waterproof, One per Duplexer
Ambient operating temperature-40 to 55° C (-40 to 131° F)
CertificationsCE, FCC, IC
Software
ModesSISO/MIMO
System
Max. throughput1.2+ Gbps
Max. range300+ km
Encryption128-bit AES
RF
Operating frequency*10.7-11.7 GHz
*Depends on regional regulations.
Max. conducted TX power*30 dBm
*Depends on regional regulations.
Frequency accuracy± 1 ppm
Channel bandwidth*3.5/5/7/10/14/20/ 28/30/40/50/56 MHz selectable
Programmable Uplink and Downlink duty cycles
* For region-specific details, refer to the Compliance chapter of the airFiber AF-11FX User Guide at ui.com/download/airfiber
